Weidmüller 1000910000 BLDF 5.08/07/180 SN BK BX: Technical Guide to a 7-Pole Female Plug
The Weidmüller 1000910000 BLDF 5.08/07/180 SN BK BX is a 7-pole female PCB plug designed for industrial applications that need removable wiring, fast installation, and dependable electrical performance. It is part of a connector family widely used in control electronics, modular automation systems, and compact industrial devices where practical field handling is just as important as specification fit.
Product Structure and Design Intent
The designation Weidmüller 1000910000 BLDF 5.08/07/180 SN BK BX female plug describes a connector with a 5.08 mm pitch, 7 poles, and a 180-degree straight conductor outlet. The product uses PUSH IN with actuator technology and supports a maximum clamping range of 3.31 mm². These characteristics make it well suited to projects that require efficient wiring workflows and a clean pluggable board connection strategy.
Why the 7-Pole Version Has Practical Value
The Weidmüller BLDF 5.08/07/180 SN BK BX is useful in designs that need more circuits than a basic control connector but still want to remain in a compact and familiar format. Seven-pole configurations appear in automation modules, machine interface boards, monitoring systems, building controls, and multi-function device electronics where grouping several connections in one removable component can simplify both assembly and service.
The 5.08 mm pitch contributes to comfortable installation, especially in industrial conditions where access is limited and fast, reliable conductor handling is valuable. In that sense, the connector helps support both design efficiency and practical usability.
Electrical Performance
The listed product data specifies 400 V / 20.8 A under IEC with a conductor range of 0.2 to 2.5 mm². Under UL, the product is rated at 300 V / 18.5 A with a wire range of AWG 12 to AWG 26. These values make the Weidmüller 1000910000 connector suitable for many industrial signal and moderate power-related PCB applications.
Typical Applications
The Weidmüller 1000910000 BLDF 5.08/07/180 SN BK BX female plug is well suited to control systems, automation equipment, serviceable PCB modules, compact machine electronics, and industrial interface boards. Because it belongs to a broader family, it also supports product-platform consistency where different pole counts are needed across related designs.
Common product searches include Weidmüller 1000910000, Weidmüller BLDF 5.08/07/180 SN BK BX, and Weidmüller 7-pole female plug. These terms are valuable for cataloging, maintenance lookup, and cross-functional documentation.
FAQ
What type of connector is Weidmüller 1000910000?
It is a female PCB plug for removable wire-to-board connection.
How many poles does it have?
The connector has 7 poles.
What pitch does the connector use?
It uses a 5.08 mm pitch.
What connection technology is included?
It uses PUSH IN with actuator technology for efficient conductor handling.
What are the rated values?
The listed values are 400 V / 20.8 A under IEC and 300 V / 18.5 A under UL.
Where is the connector commonly used?
It is commonly used in industrial control systems, automation devices, interface boards, and service-friendly PCB assemblies.
For more about Weidmüller, comparing the full BLDF range can help align connector choice with future product expansion.
