Weidmüller 1000130001 BLF 5.08HC/12/90 SN BK BX Technical Overview
The Weidmüller 1000130001 BLF 5.08HC/12/90 SN BK BX PCB plug-in connector is a 12-pole female plug engineered for removable wire-to-board connectivity in industrial devices and control electronics. When teams search for a 12-pole PCB connector, a 5.08 mm pluggable terminal block, or a Weidmüller right-angle industrial connector, this model offers a strong combination of density, clarity, and installation logic.
The Weidmüller BLF 5.08HC/12/90 SN BK BX is especially relevant where multiple conductors must be grouped into one board interface without sacrificing structured wiring. In industrial design, this can support cleaner layouts, fewer connection points, and a more serviceable product architecture overall.
Why 12 Poles Can Be the Right Choice
As electronic products become more feature-rich, the number of external conductors often grows. A 12-pole connector can accommodate control lines, auxiliary power, feedback channels, and communication-related wiring in a single interface. That reduces fragmentation and can make the assembly easier for both production teams and field technicians.
The Weidmüller 1000130001 PCB connector is therefore a strong fit for applications where connection grouping matters as much as raw electrical performance. Clear interface structure supports better documentation, easier wiring inspection, and more intuitive maintenance.
Technical Design Perspective
The Weidmüller 1000130001 BLF 5.08HC/12/90 SN BK BX female plug is built on a 5.08 mm pitch and uses a 90-degree wire entry format. It employs PUSH IN spring connection technology with actuator support and is intended as a removable connector for PCB systems. This positions it well for environments where assembly efficiency and reliable conductor retention are both strategic priorities.
Right-angle entry continues to be a major benefit in compact enclosures. It allows conductors to follow a controlled path along the mechanical layout of the device, which often improves cable management and helps maintain a tidy internal arrangement.
Weidmüller 1000130001 Typical Applications
The Weidmüller 12-pole pluggable terminal block can be used in control units, monitoring electronics, modular I/O, OEM subsystems, building automation boards, instrumentation equipment, and compact machine interfaces. Where a device needs a removable twelve-line connection, this model provides an efficient and technically coherent answer.
It is also a practical choice for OEM platforms that rely on connector family standardization. Selecting a familiar Weidmüller series across several products helps simplify documentation, service training, and component sourcing.
For more information about Weidmüller, reviewing adjacent connector variants in the same family can help define a consistent platform strategy.
Long-Term Value in Industrial Systems
In industrial product design, long-term serviceability is often as important as first-time assembly speed. The Weidmüller 1000130001 supports a removable interface concept, which can make repairs, board replacement, and inspection more manageable. That can reduce downtime and improve the service experience over the life of the equipment.
This is one reason established connector families remain relevant. They do not just solve an immediate connection requirement. They contribute to how the product performs operationally and how efficiently it can be supported years after installation.
Weidmüller 1000130001 FAQ
What is the main use of the Weidmüller 1000130001?
Its main use is to provide a removable 12-pole wire-to-board interface for industrial electronics, control systems, and modular devices.
Why would an engineer choose a 12-pole connector?
A 12-pole connector is useful when many related conductors must be grouped into one organized interface while maintaining a clean and serviceable board layout.
Is this model suitable for compact enclosures?
Yes. The 90-degree wire entry helps route conductors efficiently in applications where vertical space is limited.
Does the PUSH IN system offer a practical advantage?
Yes. It supports faster and more consistent conductor handling, which can be valuable during assembly and maintenance.
Can this connector support product family standardization?
Yes. Because it belongs to a broader connector family, it can fit well into multi-product platforms that require consistent connection logic.
