Telemecanique XZCPV1865L2 1/2-20 UNF Sensor Cable

The Telemecanique XZCPV1865L2 1/2-20 UNF sensor cable is a pre-wired connector cable designed for industrial automation applications that require a straight female 1/2-20 UNF connection. It has 3 pins, a 2 meter PVC cable, metal collar, 3 x 0.34 mm² cable composition, 250 V AC and 300 V DC rated operational voltage, 1 Gohm insulating resistance, IP65 and IP67 protection, and cULus certification.

Technical Overview

This cable is part of the Telemecanique XZ pre-wired connector range and is intended for reliable connection between compatible field devices and automation equipment. Unlike M12 versions, the XZCPV1865L2 uses a 1/2-20 UNF connector format. This makes it relevant for installations where legacy equipment, specific sensor designs, or machine standards require this thread type.

Industrial Use and Compatibility

The straight female connector is useful where direct cable routing is available and the device connection does not require an angled exit. Its PVC cable jacket supports general industrial use, while the 2 meter length keeps wiring controlled in compact layouts. The 3-pin arrangement is practical for many sensor and field device connections.

Why Rated Voltage Matters

The XZCPV1865L2 has a higher rated operational voltage than the M12 PVC models in this group, with 250 V AC and 300 V DC ratings. This makes specification checking especially important. Engineers and maintenance teams should always compare the cable rating with the connected device, system voltage, and applicable safety documentation.

For more Telemecanique product information, visit Telemecanique information.

FAQ

What is the Telemecanique XZCPV1865L2 used for?

It is used as a pre-wired 1/2-20 UNF sensor cable in industrial automation systems. It connects compatible sensors or field devices where this connector format is required.

What connector type does it have?

It has a straight female 1/2-20 UNF connector with 3 pins. This differs from M12 connector cables and should be selected only when the equipment requires this format.

How long is the XZCPV1865L2 cable?

The cable length is 2 meters. This makes it suitable for short routing distances in machines, panels, and field-level automation assemblies.

What is the rated operational voltage?

The rated operational voltage is 250 V AC and 300 V DC. This should be verified against the connected device and installation requirements before use.

Does it have environmental protection?

Yes. The cable has IP65 and IP67 protection ratings when installed correctly with compatible components, supporting use in many industrial environments.
