Telemecanique XZCPV0941L10

Telemecanique XZCPV0941L10 Pre-Wired Connector: 4-Pin M12 Female Industrial Cordset

The Telemecanique XZCPV0941L10 pre-wired connector is a molded industrial cordset engineered to provide standardized M12 connectivity between sensors and control systems. Designed for machine-level integration, this connector eliminates field termination variability and enhances installation repeatability across automated production environments.

Technical Specifications

  • Brand + code + type: Telemecanique XZCPV0941L10 pre-wired connector
  • Connector type: Straight female M12
  • Pin configuration: 4-pin
  • Cable length: 10 meters
  • Cable material: PVC jacket
  • Coupling mechanism: Screw-lock metal collar

M12 4-Pin Electrical Architecture

The Telemecanique XZCPV0941L10 pre-wired connector supports four conductors, typically used in DC sensor wiring configurations. The molded design ensures consistent conductor mapping and stable insulation performance, reducing commissioning errors associated with manual termination.

Mechanical Integrity and Vibration Resistance

The screw-lock coupling system secures the connector against vibration-induced loosening. Proper torque application during installation ensures mechanical stability and long-term electrical continuity in dynamic industrial machinery.

Cable Routing and Installation Governance

The PVC cable construction of the Telemecanique XZCPV0941L10 pre-wired connector allows flexible routing in control cabinets, cable trays, and moving machine assemblies. Correct strain relief and adherence to recommended bend radius prevent conductor fatigue and insulation stress.

For compatible industrial sensing devices, visit Telemecanique sensor.

FAQ

  • Is this connector field-attachable? — No, it is factory molded.
  • How many pins does it have? — 4-pin.
  • What is the cable length? — 10 meters.
  • What connector format is used? — M12 female.
  • Primary use? — Industrial sensor connectivity.

Entity recap: The Telemecanique XZCPV0941L10 pre-wired connector is a 4-pin M12 industrial cordset for standardized automation wiring.
