Telemecanique XUN5ANXNM12 Ultrasonic Sensor: Technical Specifications and Industrial Applications
The Telemecanique XUN5ANXNM12 ultrasonic sensor is engineered for non-contact detection in applications where optical sensing may be limited by color variation, transparency, or reflective surfaces. Using ultrasonic wave propagation and echo measurement, this model ensures stable distance detection within a compact industrial housing. The M12 connector interface supports maintainable wiring practices and faster replacement cycles in automated production lines.
Operating Principle of the Telemecanique XUN5ANXNM12 Ultrasonic Sensor
The Telemecanique XUN5ANXNM12 ultrasonic sensor emits high-frequency sound pulses and calculates the distance of an object based on the time required for the echo to return. Because ultrasonic sensing is independent of surface color or ambient light, it performs consistently in environments with transparent films, dark plastics, or glossy metals. This makes it particularly suitable for packaging systems, liquid level monitoring, and object positioning tasks.
Key Technical Specifications
- Product type: Ultrasonic sensor (Telemecanique XUN series)
- Detection range: 0.05–0.5 m
- Supply voltage: 12–24 V DC (typically 10–30 V DC operating limits)
- Output type: PNP/NPN configurable discrete output
- Electrical connection: M12 male connector
- Response time: ≤ 50 ms
- Protection rating: IP67
- Housing material: Industrial-grade plastic
- Operating temperature: -25…70 °C
These parameters indicate that the Telemecanique XUN5ANXNM12 ultrasonic sensor is optimized for medium-range detection in industrial automation. The 0.05–0.5 m range provides flexibility for compact machinery while maintaining reliable object tracking.
Installation and Commissioning Guidelines
When installing the Telemecanique XUN5ANXNM12 ultrasonic sensor, ensure that the sensing surface is aligned perpendicularly to the target whenever possible. Avoid placing angled reflective surfaces directly in the beam path, as echo deviation may affect repeatability. The M12 connector simplifies installation and supports standardized cabling across machine platforms.
For consistent sensor strategy across projects, reviewing complementary models within the Telemecanique sensor category helps standardize voltage, connector type, and spare part planning.
Industrial Application Areas
- Liquid level detection: Suitable for tanks containing water or process fluids.
- Transparent object detection: Reliable for glass or film materials.
- Box positioning: Ensures accurate placement in conveyor systems.
- Packaging verification: Confirms product presence prior to sealing.
Because ultrasonic technology is immune to light interference, the Telemecanique XUN5ANXNM12 ultrasonic sensor is frequently selected in environments with varying ambient illumination.
FAQ
1) What detection range does XUN5ANXNM12 provide?
The Telemecanique XUN5ANXNM12 ultrasonic sensor operates within 0.05–0.5 meters.
2) Is it affected by object color?
No, ultrasonic detection works independently of surface color or transparency.
3) What voltage is required?
It operates on 12–24 V DC supply.
4) What protection rating does it have?
The sensor is rated IP67 for industrial environments.
5) What connector type is used?
An M12 male connector is provided for electrical connection.
