Telemecanique XUN5ANXNL2 Ultrasonic Sensor: Performance and Configuration

The Telemecanique XUN5ANXNL2 ultrasonic sensor is designed for reliable object detection independent of color, transparency, or surface reflectivity. Ultrasonic technology measures distance by emitting sound waves and analyzing echo return time, making it ideal for challenging environments.

Technical Specifications

• Detection range: 0.05–0.5 m
• Supply voltage: 12–24 V DC
• Output: PNP/NPN configurable
• Connection: Cable (2 m)
• IP rating: IP67
• Response time: ≤ 50 ms

The Telemecanique XUN5ANXNL2 ultrasonic sensor performs consistently in dusty or humid environments where optical sensors may struggle. It is commonly used for level detection, object presence verification, and packaging control.

To maintain consistent sensor selection policies, engineers may review additional models in the Telemecanique sensor range.

Applications

• Liquid level monitoring
• Transparent object detection
• Box dimension verification

FAQ

1) What is detection range?

0.05–0.5 m operating range.

2) Can it detect transparent materials?

Yes, ultrasonic detection is independent of transparency.

3) What voltage is required?

12–24 V DC.

4) What protection class?

IP67 rated housing.

5) Is output configurable?

Yes, PNP or NPN selectable.
