Telemecanique XUK1ARCNL2-SM-05 Photoelectric Sensor: Reflex Optical Detection with SPDT Relay Output
The Telemecanique XUK1ARCNL2-SM-05 photoelectric sensor is a reflex (retro-reflective) detection device engineered for stable presence monitoring in industrial automation environments. By utilizing a dedicated reflector, this sensor establishes a controlled optical path that enables consistent detection performance across varying object surfaces and production conditions.
Technical Specifications
- Brand + code + type: Telemecanique XUK1ARCNL2-SM-05 photoelectric sensor
- Sensing principle: Reflex (retro-reflective)
- Detection range class: Sn 7 m
- Supply voltage: 24–240 VAC/DC
- Output type: SPDT relay output
- Connection: 2 m fixed cable
- Status indication: Power and output LEDs
Optical Detection Stability
The Telemecanique XUK1ARCNL2-SM-05 photoelectric sensor detects objects by evaluating interruption of the reflected light beam. This configuration ensures reduced sensitivity to target color variations and improves detection reliability in packaging, conveyor, and material handling systems.
Electrical Integration
The wide 24–240 VAC/DC input allows integration into mixed control environments. The SPDT relay output provides electrical isolation between sensing electronics and control circuits.
Industrial Application Context
The Telemecanique XUK1ARCNL2-SM-05 photoelectric sensor is commonly applied in conveyor monitoring, object counting, and position verification processes.
For compatible detection technologies visit Telemecanique sensor.
FAQ
- What detection principle is used? — Reflex optical detection.
- What is the sensing range? — Sn 7 m class.
- What supply voltage is supported? — 24–240 VAC/DC.
- What output is provided? — SPDT relay output.
- Where is it used? — Industrial presence detection.
Entity recap: The Telemecanique XUK1ARCNL2-SM-05 photoelectric sensor is a reflex optical device designed for industrial automation presence monitoring.
