Telemecanique XS630B1DBM12 Inductive Proximity Sensor: Extended Range Metal Detection
The Telemecanique XS630B1DBM12 inductive proximity sensor is designed for reliable non-contact metal detection in industrial automation systems. Featuring a robust M30 cylindrical threaded housing and a 15 mm nominal sensing distance, this model is engineered to deliver stable detection in demanding mechanical environments. Its PNP output configuration and M12 connector interface support standardized electrical integration across modern PLC-based systems.
Technical Specifications of Telemecanique XS630B1DBM12 Inductive Proximity Sensor
- Sensing distance (Sn): 15 mm
- Housing size: M30 cylindrical, nickel-plated brass
- Mounting type: Non-flush mountable
- Output type: PNP, normally open
- Supply voltage: 12–24 V DC
- Electrical connection: M12 male connector
- Switching frequency: Up to 200 Hz
- Protection rating: IP67
- Operating temperature: -25…70 °C
The Telemecanique XS630B1DBM12 inductive proximity sensor detects ferrous and non-ferrous metallic objects without physical contact, minimizing wear and extending operational lifespan. The non-flush mounting requirement ensures optimal sensing field performance when properly installed with sufficient clearance from surrounding metal structures.
Installation and Integration Considerations
Proper installation of the Telemecanique XS630B1DBM12 inductive proximity sensor requires adherence to recommended mounting distances to prevent electromagnetic interference from adjacent metallic surfaces. The M12 connector provides reliable vibration-resistant connectivity and simplifies maintenance replacement procedures.
For system-wide standardization and accessory compatibility, additional models can be reviewed within the Telemecanique sensor portfolio.
Application Areas
- Conveyor metal detection
- Machine position monitoring
- Actuator end-stop confirmation
- Automated assembly fixtures
FAQ
1) What is the sensing distance?
The Telemecanique XS630B1DBM12 inductive proximity sensor provides a 15 mm nominal sensing distance.
2) What output configuration is included?
PNP normally open output.
3) Is it flush mountable?
No, it is designed for non-flush mounting.
4) What connector type is used?
M12 male connector.
5) What protection rating is provided?
IP67 industrial protection rating.
