Telemecanique XS630B1DAM12 Inductive Proximity Sensor: Reliable Metal Detection for Industrial Automation
The Telemecanique XS630B1DAM12 inductive proximity sensor is engineered for extended-range metal detection in demanding automation environments. Built with an M30 cylindrical threaded housing and offering a 15 mm nominal sensing distance, this model is optimized for non-contact detection of metallic objects. Its NPN normally open output configuration and standardized M12 connector interface simplify integration into PLC-controlled systems.
Technical Specifications of Telemecanique XS630B1DAM12 Inductive Proximity Sensor
- Sensing distance (Sn): 15 mm
- Housing type: M30 cylindrical, nickel-plated brass
- Mounting: Non-flush mountable
- Output type: NPN, normally open
- Supply voltage: 12–24 V DC
- Electrical connection: M12 male connector
- Switching frequency: Up to 200 Hz
- Protection rating: IP67
- Operating temperature: -25…70 °C
The Telemecanique XS630B1DAM12 inductive proximity sensor is particularly suited for applications requiring reliable detection without physical contact, minimizing mechanical wear and improving long-term system reliability.
Installation and Mounting Guidelines
Because the Telemecanique XS630B1DAM12 inductive proximity sensor is non-flush mountable, sufficient clearance from surrounding metal structures must be maintained. Proper installation ensures consistent electromagnetic field behavior and accurate detection performance.
For complementary sensor technologies and standardized accessories, engineers may review the Telemecanique sensor portfolio to maintain compatibility across automation systems.
Typical Applications
- Machine end-position detection
- Conveyor metal presence monitoring
- Actuator position confirmation
- Industrial automation fixtures
FAQ
1) What is the sensing distance?
The Telemecanique XS630B1DAM12 inductive proximity sensor provides a 15 mm nominal sensing distance.
2) What output configuration does it use?
NPN normally open output.
3) Is it flush mountable?
No, it requires non-flush mounting.
4) What connector type is included?
M12 male connector.
5) What protection rating is provided?
IP67 industrial protection rating.
