Panasonic FT-45X Threaded Type Fiber: Precision Sensing for Industrial Automation
The Panasonic FT-45X threaded type fiber is a high-precision thrubeam fiber designed for industrial automation. With its M3 threaded fiber design, 2m cuttable cable, R2 bend radius, and IP67 protection, the FT-45X excels in demanding applications like factory automation and material handling detection. Its small object detection capability, advanced sensing technology, and industrial network compatibility make it an ideal choice for automation sensor solutions. The durable FT-45X industrial fiber sensor offers easy installation and reliable performance, boosting efficiency across various industrial sectors.
Technical Specifications of Panasonic FT-45X Threaded Type Fiber
The Panasonic FT-45X threaded type fiber combines a compact design with high precision to meet industrial demands. Below is a table of its key technical specifications:
| Parameter | Specification |
|---|---|
| Fiber Type | Thrubeam, M3 threaded |
| Cable Length | 2m, cuttable |
| Bend Radius | R2 (2 mm) |
| Protection Rating | IP67 |
| Sensing Distance | Up to 720 mm with FX-500 series (STD mode) |
| Compatibility | FX-500, FX-550, FX-100 series amplifiers |
| Standards | RoHS compliant (2011/65/EU, 2015/863/EU) |
Industrial Applications and Key Features
Small Object Detection and High-Precision Sensing Technology
The Panasonic FT-45X threaded type fiber is optimized for small object detection, making it ideal for industries such as electronics assembly, food processing, and packaging. The high-precision FT-45X fiber cable, equipped with advanced PCTC polishing technology, maintains beam axis deviation within ±3º and centering accuracy within ±150µm. This FT-45X sensing technology ensures reliable performance in applications requiring high accuracy, enhancing operational consistency and productivity.
Durability and Factory Automation
The durable Panasonic FT-45X threaded type fiber, with its IP67 protection rating, is resistant to dust and water, ensuring reliable operation in harsh environments. Widely used in conveyor system sensing and material handling detection, the FT-45X’s R2 bend radius fiber offers flexibility for complex installations. As a robust FT-45X factory automation fiber, it delivers long-term performance in automated assembly lines, supporting seamless production processes.
Industrial Network Compatibility and System Integration
Compatible with Panasonic’s FX-500, FX-550, and FX-100 series amplifiers, the FT-45X ensures seamless industrial network compatibility. Its optical communication function enables rapid configuration of multiple amplifiers, reducing setup time. The FT-45X fiber optic datasheet and FT-45X fiber optic installation guide, available through Panasonic’s official resources, provide detailed instructions for efficient system integration, streamlining automation processes.
Installation and Maintenance
The FT-45X’s M3 threaded design and 2m cuttable fiber cable simplify installation, while the R2 bend radius enhances flexibility in tight spaces. The IP67 fiber sensor operates reliably in humid or dusty environments, and the FT-45X fiber optic installation guide offers step-by-step setup instructions. Regular cleaning of fiber ends, a simple maintenance task, ensures the long-term reliability of this durable industrial fiber sensor.
Safety and Compliance
The FT-45X is RoHS compliant (2011/65/EU, 2015/863/EU), reflecting its environmentally friendly design. Its IP67 protection ensures durability in challenging industrial settings. Operating stably between -55°C and +80°C, the FT-45X high-precision fiber sensor is a dependable choice for factory automation.
Why Choose Panasonic FT-45X Threaded Type Fiber?
The Panasonic FT-45X fiber optic sensor is a high-precision, durable solution for industrial automation. Its M3 threaded fiber, 2m cuttable cable, and R2 bend radius provide flexible installation options. With capabilities for small object detection, material handling detection, and conveyor system sensing, the FT-45X boosts production efficiency. The FT-45X fiber optic datasheet and installation guide facilitate integration, ensuring operational success. Choose the FT-45X to elevate automation, achieve precision, and enhance productivity in your operations.
Visit our blog about The Importance of Sensors in Industry 4.0.
Compact Design for Precision Detection in Tight Spaces
The Panasonic FT-45X threaded type fiber stands out for its compact M3 threaded structure, making it ideal for limited-space installations and high-density automation systems. Its R2 bend radius provides exceptional flexibility for routing within narrow equipment or robotic systems, allowing smooth cable management without signal loss. Designed for precision tasks like micro-component detection, packaging verification, and robotic pick-and-place operations, the FT-45X ensures stable performance even under vibration or fast motion environments. Its 2m cuttable fiber cable offers installation adaptability for various machine layouts, improving system integration efficiency.
Using advanced PCTC polishing technology, the FT-45X enhances optical transmission quality, providing consistent detection of small, transparent, or low-contrast objects. The sensor’s high light-intensity output, combined with its ±3º beam axis alignment and ±150µm centering precision, guarantees repeatable and error-free operation. This makes it a superior choice for assembly lines, electronic component testing, and high-speed conveyor systems, where accuracy and reliability are crucial for productivity and quality assurance.
Reliable Performance in Harsh Industrial Conditions
Engineered for durability, the FT-45X fiber sensor features IP67 protection against dust, water, and mechanical stress, ensuring uninterrupted operation in demanding industrial environments. It performs consistently in temperatures ranging from -55°C to +80°C, providing robust functionality in both refrigerated and high-heat production areas. When paired with Panasonic FX-500, FX-550, or FX-100 amplifiers, the FT-45X achieves seamless industrial network integration, supporting fast and accurate configuration via optical communication functions.
The Panasonic FT-45X threaded type fiber delivers the perfect balance of precision, durability, and ease of installation. Its RoHS-compliant design emphasizes environmental responsibility while meeting the strict performance demands of modern factory automation. By choosing the FT-45X, manufacturers gain a long-lasting sensing solution that ensures exceptional accuracy, flexibility, and efficiency across industrial applications.
