Panasonic DP-101-N-J Sensor: Technical Specifications, Applications, and Buying Guide
What is the Panasonic DP-101-N-J Sensor?
The Panasonic DP-101-N-J sensor is a digital pressure sensor specifically developed for systems requiring pressure measurement and control. With its compact design, high-precision measurement capability, and easy installation, it is used in both small- and large-scale projects. The sensor offers seamless integration with modern data processing systems, making it a reliable component in automation processes.
Technical Specifications
Technical specifications of the DP-101-N-J sensor include:
- Pressure Range: Measures between -100 kPa and 1 MPa.
- Accuracy: ±%0.5 FS (Full Scale)
- Output Type: Digital (PNP/NPN)
- Operating Temperature: Stable performance between -10°C and 50°C.
- Power Supply: 12-24V DC
- Mounting Type: Suitable for panel and surface mounting.
- Display: User-friendly digital screen for easy monitoring.
- Dimensions: Compact design (24 x 30 x 10 mm).
Applications
The Panasonic DP-101-N-J sensor is versatile and can be used across various industries. Key applications include:
- Industrial Automation: Provides pressure control in pneumatic and hydraulic systems, enhancing efficiency in production lines.
- Medical Devices: Preferred in respiratory devices, blood pressure monitors, and other precision-required medical applications.
- Automotive Industry: Delivers reliable performance in engine pressure measurements, fuel injection systems, and vehicle climate control systems.
- Food and Beverage Industry: Hygienic models are used in liquid filling, packaging, and other production processes.
- Research and Development Laboratories: Ideal for conducting precise pressure measurements during testing and analysis.
- Electronics Manufacturing: Widely used in vacuum systems and airflow control in electronics production lines.
Benefits of the DP-101-N-J Sensor
The Panasonic DP-101-N-J sensor provides several advantages to meet users’ needs:
- High Precision: ±%0.5 FS accuracy detects even the smallest pressure changes.
- Compact Design: Easily fits into tight spaces due to its small size.
- Durability: Provides long-lasting performance in challenging environmental conditions.
- Energy Efficiency: Operates with low power consumption, reducing operational costs.
- User-Friendly Interface: Real-time pressure values can be easily monitored using the digital display.
- Easy Installation: Quick and simple setup with options for panel or surface mounting.
- Wide Application Range: Suitable for diverse industries.
Installation and Calibration Process
Installation Guide
- Panel or Surface Mounting: The sensor can be mounted into panel slots or secured to a flat surface. Ensure the digital display is visible.
- Electrical Connections: Properly connect the power supply and output terminals. Once all connections are complete, the sensor is ready for use.
Calibration Process
Calibration ensures accurate measurements. The process includes:
- Connect the sensor to a power source.
- Apply correct pressure using a reference pressure device.
- Adjust the displayed values on the sensor to match the reference pressure.
Buying Process
Price and Stock Availability
The price of the Panasonic DP-101-N-J sensor varies depending on the order quantity and distributor. Contact Panasonic’s authorized distributors for pricing and stock availability.
Buying Tips
- Purchase from Authorized Distributors: Ensure authenticity and technical support by buying from Panasonic’s authorized distributors.
- Online Stores: Take advantage of fast delivery by shopping on reliable e-commerce platforms.
- Request a Quote: Get discounts for bulk orders by requesting quotes from distributors.
Frequently Asked Questions (FAQs) About the DP-101-N-J Sensor
- 1. Which industries use the DP-101-N-J sensor?
- It is widely used in industrial automation, medical devices, automotive, food, and electronics manufacturing industries.
- 2. What is the accuracy level?
- It provides ±%0.5 FS accuracy for high-precision measurements.
- 3. Is the installation process easy?
- Yes, the compact design and user-friendly mounting options make installation simple.
- 4. How often should calibration be performed?
- Calibration is recommended during initial setup and at regular maintenance intervals.
- 5. What is the operating temperature range?
- The sensor performs reliably between -10°C and 50°C.
- 6. How much does the sensor cost?
- Pricing depends on the order quantity and distributor. Contact distributors for detailed information.
Conclusion
The Panasonic DP-101-N-J sensor is a reliable solution for industrial automation and pressure measurement with its compact design, high precision, and durability. Its wide range of applications and user-friendly features make it suitable for both small and large-scale projects. Contact Panasonic’s authorized distributors for a seamless purchasing process.
Related Articles: Learn more about the sensors by reading our blog on What is a Pressure Sensor? Where is it Used?
Why Choose the Panasonic DP-101-N-J Sensor?
Panasonic DP-101-N-J sensor stands out in the market with its combination of precision, durability, and flexibility. It is specifically engineered for industries that require reliable pressure control under demanding conditions. The sensor’s digital output enables seamless integration with PLC systems and modern automation setups, making it an essential part of Industry 4.0 applications. Its compact structure not only saves installation space but also ensures that it can be mounted in complex production environments without compromising accuracy. Thanks to its ±%0.5 FS accuracy, it provides dependable results in critical processes such as medical equipment, automotive applications, and electronic manufacturing lines.
DP-101-N-J pressure sensor also contributes to operational efficiency by offering low energy consumption and long-term reliability, reducing downtime and maintenance costs. Its user-friendly display simplifies real-time monitoring, allowing operators to quickly respond to system changes. Regular calibration ensures continued accuracy, making it a valuable investment for businesses aiming to enhance productivity. Whether used in research laboratories, food processing, or heavy industry, the Panasonic DP-101-N-J sensor delivers consistent performance. For those seeking a pressure sensor that combines advanced technology with practical usability, this model represents a cost-effective and future-ready solution.
