Panasonic DP-101-M Sensor: Technical Specifications, Applications, and Buying Guide
What is the Panasonic DP-101-M Sensor?
The Panasonic DP-101-M sensor is a digital pressure sensor used in various industrial processes requiring pressure control. Its compact design and user-friendly interface make it suitable for pneumatic and hydraulic systems as well as laboratory testing devices. With high accuracy and reliable performance, it is a critical component for industrial automation systems.
Technical Specifications
Technical specifications of the DP-101-M sensor include:
- Pressure Range: Measures between -100 kPa and 1 MPa.
- Accuracy: ±%0.5 FS (Full Scale)
- Output Type: Digital (PNP/NPN)
- Operating Temperature: Stable performance between -10°C and 50°C.
- Power Supply: 12-24V DC
- Mounting Type: Suitable for panel or surface mounting.
- Dimensions: Compact design (24 x 30 x 10 mm).
- Display: User-friendly digital screen for real-time pressure values.
Applications
The Panasonic DP-101-M sensor is versatile and durable, making it suitable for a variety of industries. Key applications include:
- Industrial Automation: Provides pressure control in pneumatic and hydraulic systems. Enhances efficiency by balancing pressure in production lines.
- Medical Devices: Used in respiratory devices, medical testing equipment, and other precision-required medical applications.
- Automotive Industry: Reliable for engine pressure measurements, fuel injection systems, and vehicle air conditioning systems.
- Food and Beverage Industry: Hygienic models are preferred for liquid filling and packaging lines.
- Electronics Manufacturing: Ensures precise measurement in airflow control and vacuum systems.
- Research and Development Laboratories: Plays a critical role in pressure measurement devices for testing and analysis processes.
Benefits of the DP-101-M Sensor
The Panasonic DP-101-M sensor offers many advantages to users:
- High Precision: Provides high accuracy in pressure measurements with ±%0.5 FS sensitivity.
- Compact Design: Easily mountable in tight spaces due to its small dimensions.
- Durability: Long-lasting and reliable even in challenging environmental conditions.
- Energy Efficiency: Operates with low power consumption, reducing operational costs.
- User-Friendly Display: The digital display allows for easy monitoring of real-time pressure values.
- Easy Installation: Panel or surface mounting options enable easy integration into different systems.
- Wide Application Range: Suitable for use across various industries and projects.
Installation and Calibration Process
Installation Guide
- Panel or Surface Mounting: The sensor can be easily placed into slots on a panel or mounted on a flat surface. Ensure the digital display is visible when panel-mounted.
- Electrical Connections: Properly connect the power supply and output terminals. Once all connections are secure, the sensor is ready for use.
Calibration Process
Calibration is essential for precise measurements. The process includes:
- Connect the sensor to a power source.
- Apply accurate pressure using a reference pressure device.
- Adjust the displayed values on the sensor to match the reference pressure.
Buying Process
Price and Stock Availability
The price of the Panasonic DP-101-M sensor varies depending on the order quantity and supplier. Contact Panasonic’s authorized distributors for up-to-date pricing and stock information.
Buying Tips
- Purchase from Authorized Distributors: Buy from Panasonic’s authorized distributors to ensure product authenticity and technical support.
- Online Stores: Take advantage of fast delivery by shopping on reliable e-commerce platforms.
- Request a Quote: Get discounts for bulk orders by requesting quotes from distributors.
Frequently Asked Questions (FAQs) About the DP-101-M Sensor
- 1. Which industries use the DP-101-M sensor?
- It is used in industrial automation, medical devices, automotive, food, and electronics manufacturing industries.
- 2. What is the accuracy level of the sensor?
- The sensor operates with ±%0.5 FS accuracy, ensuring precise measurements.
- 3. Is the installation process easy?
- Yes, it is easy to install with its compact design and user-friendly mounting options.
- 4. How often should calibration be performed?
- Calibration is recommended during initial setup and at regular maintenance intervals.
- 5. What is the operating temperature range?
- The sensor performs reliably between -10°C and 50°C.
- 6. How much does the sensor cost?
- The price depends on the order quantity and supplier. Contact distributors for detailed pricing information.
Conclusion
The Panasonic DP-101-M sensor is an ideal solution for industrial applications requiring precise pressure measurement and control. With its technical specifications and wide application range, it is suitable for both small and large-scale projects. For a seamless buying process, contact Panasonic’s authorized distributors.
Related Articles: Learn more about the sensors by reading our blog on What is a Pressure Sensor? Where is it Used?
Long-Term Advantages of the DP-101-M Sensor
The Panasonic DP-101-M sensor not only provides precise pressure measurements but also ensures long-term reliability for demanding industrial applications. Its durable construction and compact design make it suitable for harsh environments where space is limited. Thanks to its low power consumption, the DP-101-M reduces operational costs while delivering consistent accuracy of ±%0.5 FS, which is essential for maintaining stable processes. Whether used in hydraulic systems, medical devices, or electronic manufacturing, the sensor helps increase productivity by offering quick response times and dependable results. For industries that prioritize efficiency and safety, this sensor stands out as a cost-effective and reliable option.
Another major advantage of the DP-101-M pressure sensor is its user-friendly digital display and flexible mounting options. Engineers and technicians can easily monitor real-time pressure values, perform adjustments, and carry out system optimization without complications. When properly calibrated, the sensor maintains long-lasting measurement stability, reducing the need for frequent recalibrations. This makes it especially valuable for continuous operation environments such as production lines and laboratory testing setups. By sourcing the DP-101-M from Panasonic’s authorized distributors, users also gain access to original product warranties and technical support, ensuring a safe and smooth purchasing experience.
