Panasonic DP-101-M-P Sensor: Technical Specifications, Applications, and Buying Guide



The Panasonic DP-101-M-P sensor is a compact, high-precision device designed for industrial automation and pressure measurement systems. With digital output features, a durable design, and a wide range of applications, this sensor plays a critical role in modern industrial systems. This article provides detailed information on the technical specifications, benefits, applications, and purchasing processes for the DP-101-M-P sensor.

What is the Panasonic DP-101-M-P Sensor?

The Panasonic DP-101-M-P sensor is a pressure sensor specifically developed for applications requiring pressure measurement and control. Its compact design and digital display make it user-friendly, offering high-precision measurement capabilities. It is a reliable choice for various industries, including pneumatic systems and medical devices.

Technical Specifications

The technical specifications of the Panasonic DP-101-M-P sensor are as follows:

  • Pressure Range: Measures between -100 kPa and 1 MPa.
  • Accuracy: ±%0.5 FS (Full Scale)
  • Output Type: Digital (PNP/NPN)
  • Operating Temperature: Stable performance between -10°C and 50°C.
  • Power Supply: 12-24V DC
  • Mounting Type: Suitable for panel or surface mounting.
  • Display: User-friendly digital screen.
  • Dimensions: Compact design (24 x 30 x 10 mm).

Applications

The Panasonic DP-101-M-P sensor is versatile and can be used across various industries. Key applications include:

  1. Industrial Automation: Provides pressure control in pneumatic and hydraulic systems. Optimizes pressure balance in production lines to enhance efficiency.
  2. Medical Devices: Used in respiratory devices, blood pressure monitors, and other medical equipment requiring precision measurements.
  3. Automotive Industry: Delivers reliable performance in engine pressure measurement, fuel injection systems, and vehicle climate control systems.
  4. Food and Beverage Industry: Hygienic models are suitable for use in liquid filling and packaging lines.
  5. Research and Development: Performs precise measurements in laboratory testing and analysis environments.
  6. Electronics Manufacturing: Ideal for vacuum systems and airflow control applications.

Benefits of the DP-101-M-P Sensor

The Panasonic DP-101-M-P sensor offers several advantages:

  • High Precision: ±%0.5 FS accuracy allows detection of even the smallest pressure changes.
  • Compact Design: Easily fits into tight spaces due to its small dimensions.
  • Durability: Long-lasting and reliable in challenging environmental conditions.
  • User-Friendly: Real-time pressure values can be easily monitored using the digital display.
  • Energy Efficiency: Operates with low power consumption, reducing operational costs.
  • Easy Installation: Designed for quick and simple setup with options for panel or surface mounting.
  • Versatility: Suitable for a wide range of applications and industries.

Installation and Calibration Process

Installation Guide

  • Panel or Surface Mounting: The sensor can be mounted in panel slots or secured to a flat surface. Ensure the display is visible during installation.
  • Electrical Connections: Properly connect the power supply and output terminals. Once all connections are complete, the sensor is ready to use.

Calibration Process

Calibration ensures accurate measurements. The steps are as follows:

  1. Connect the sensor to a power source.
  2. Apply correct pressure using a reference pressure device.
  3. Adjust the displayed values on the sensor to match the reference pressure.

Buying Process

Price and Stock Availability

The price of the DP-101-M-P sensor varies based on order quantity and supplier. Contact Panasonic’s authorized distributors for current pricing and stock information.

Buying Tips

  • Purchase from Authorized Distributors: Ensure authenticity and technical support by buying from Panasonic’s authorized distributors.
  • Online Stores: Benefit from fast delivery by shopping on reliable e-commerce platforms.
  • Request a Quote: Get discounts for bulk orders by requesting quotes from distributors.

Frequently Asked Questions (FAQs) About the DP-101-M-P Sensor

1. Which industries use the DP-101-M-P sensor?
It is widely used in industrial automation, medical devices, automotive, food, and electronics manufacturing industries.
2. What is the accuracy level of the sensor?
The sensor provides ±%0.5 FS accuracy for precise measurements.
3. Is the installation process simple?
Yes, the compact design and user-friendly mounting options make it easy to install.
4. How often should calibration be performed?
Calibration is recommended during initial setup and at regular maintenance intervals.
5. What is the operating temperature range?
The sensor performs reliably between -10°C and 50°C.
6. How much does the sensor cost?
The price depends on the order quantity and supplier. Contact distributors for detailed pricing information.

Conclusion

The Panasonic DP-101-M-P sensor delivers high precision, durability, and user-friendly features for industrial automation and pressure measurement. Its technical specifications and wide application range make it a reliable choice for both small-scale projects and large industrial applications. Contact Panasonic’s authorized distributors for a seamless purchasing and installation experience.



Related Articles: Learn more about the sensors by reading our blog on What is a Pressure Sensor? Where is it Used?

Long-Term Advantages of the DP-101-M-P Sensor

The Panasonic DP-101-M-P sensor is more than just a compact pressure measurement device; it is a long-term investment for industries aiming to optimize their processes. With ±%0.5 FS accuracy, the sensor ensures consistent and precise readings that improve overall production quality. Its robust design makes it suitable for challenging environments, while its low power consumption contributes to energy savings and reduced operational costs. Whether used in automation systems, medical devices, or laboratory setups, the DP-101-M-P sensor enhances efficiency and ensures system stability.

Another significant benefit of the DP-101-M-P pressure sensor is its easy integration into existing systems. Thanks to its compact size and versatile mounting options, it can be installed in tight spaces without compromising functionality. The user-friendly digital display allows operators to monitor real-time values effortlessly, while the straightforward calibration process ensures long-term accuracy. By purchasing from Panasonic’s authorized distributors, users also benefit from technical support and product warranty, making the DP-101-M-P not only a reliable but also a cost-effective solution for both small-scale and large-scale industrial projects.
