Omron XS5W-T421-GM1-K Industrial Ethernet Cable

The Omron XS5W-T421-GM1-K Industrial Ethernet Cable is designed for Ethernet communication between industrial control devices equipped with different connector interfaces. Featuring a straight RJ45 connector on one end and a D-coded M12 male connector on the other, this Cat.5e cable enables reliable network integration for factory automation equipment. Its shielded construction supports stable data transmission in electrically demanding industrial environments while the factory-assembled connectors simplify installation.

Technical Description

The Omron XS5W-T421-GM1-K Industrial Ethernet Cable combines Cat.5e transmission characteristics with an SF/UTP shielded cable structure to support industrial communication networks. The cable is supplied with a straight RJ45 plug for connection to Ethernet switches, industrial PCs, PLCs, or network infrastructure, while the opposite end incorporates a D-coded M12 male connector commonly used on industrial field devices.

The 1-meter cable length is suitable for short-distance machine wiring where compact routing is preferred. The blue PVC jacket provides mechanical protection while assisting with cable identification inside automation systems.

Working Principle

This cable serves as the physical communication link between Ethernet-enabled automation devices that use different connector standards. The twisted copper conductors transmit digital Ethernet signals, while the SF/UTP shielding reduces the effects of electromagnetic interference generated by industrial equipment.

The D-coded M12 connector is widely adopted for industrial Ethernet installations because it provides secure mechanical locking and reliable electrical performance in environments subject to vibration and movement. The RJ45 connector enables straightforward integration with standard Ethernet infrastructure.

Typical Applications

• PLC communication networks
• Industrial Ethernet switches
• Remote I/O systems
• Machine automation
• Industrial sensors with Ethernet interfaces
• Control cabinet wiring
• Packaging machinery
• Factory communication networks
• Industrial vision systems
• Production equipment integration

Industrial Applications

Machine builders frequently use cables with M12 and RJ45 connectors when integrating field-level devices into centralized Ethernet networks. This configuration eliminates the need for additional adapters while maintaining standardized industrial connectivity.

Production lines equipped with distributed control systems can connect Ethernet-enabled sensors, remote I/O stations, and industrial communication modules directly to managed switches or PLCs using this cable assembly.

Automation panels also benefit from pre-assembled industrial Ethernet cables because factory-installed connectors help reduce installation time and improve consistency during commissioning.

Advantages

• Category 5e industrial Ethernet performance
• RJ45 to D-coded M12 male connectivity
• Factory-assembled connectors
• SF/UTP shielded cable construction
• Compact 1-meter cable length
• PVC outer jacket for industrial use
• Reliable communication in industrial environments
• Simplifies integration between network infrastructure and field devices

Omron XS5W-T421-GM1-K Industry Examples

Factory Automation

Industrial controllers communicate with distributed Ethernet devices installed throughout automated production equipment.

Packaging Systems

Compact machine layouts benefit from short Ethernet cable assemblies connecting PLCs and field communication modules.

Material Handling

Conveyor controllers exchange operational data with decentralized I/O devices using industrial Ethernet infrastructure.

Process Monitoring

Industrial communication networks connect monitoring devices to supervisory control systems through M12 Ethernet interfaces.

Selection Considerations

Before selecting an industrial Ethernet cable, verify connector compatibility, required cable length, shielding requirements, and installation conditions. Systems using field-mounted industrial Ethernet devices often require D-coded M12 connectors, while network switches and controllers typically use RJ45 interfaces.

Engineers should also ensure that the selected cable routing supports appropriate bend radius and mechanical protection throughout the installation.

Omron XS5W-T421-GM1-K Additional information about Omron sensor products is available for integrated industrial automation applications.

Omron XS5W-T421-GM1-K Frequently Asked Questions

1. What connector types are used on this cable?

The cable features a straight RJ45 connector on one end and a D-coded M12 male connector on the other.

2. What is the cable length?

The assembled cable length is 1 meter.

3. Which Ethernet category does it support?

The cable is manufactured according to Category 5e industrial Ethernet specifications.

4. Is the cable shielded?

Yes. It incorporates an SF/UTP shielded construction to help minimize electromagnetic interference.

5. Where is this cable commonly installed?

Typical installations include PLC systems, industrial Ethernet switches, remote I/O stations, machine controllers, and automation equipment.

6. Why is an M12 connector used?

D-coded M12 connectors provide secure locking and dependable Ethernet communication in industrial environments subject to vibration.

7. Does the cable require field assembly?

No. Both connectors are factory assembled and ready for installation.

8. What should be verified before installation?

Connector compatibility, cable routing, required length, environmental conditions, and Ethernet network architecture should all be confirmed before deployment.
