Omron WL-3A100 Limit Switch: Technical Guide, Applications and Installation
There is a reason certain relay and switch models appear in panel after panel across different industries: they simply work. The Omron WL-3A100 Limit Switch is one of those models that has become a go-to choice for general industrial limit position applications applications.
In a well-designed automation system, the sensing layer and the switching layer work in close coordination. Omron’s Omron Sensor range is engineered to feed signals directly into relays and controllers from the same manufacturer, minimising compatibility concerns and simplifying system validation.
About the Omron WL-3A100 Limit Switch
The Omron WL-3A100 is a Limit Switch, built to handle general industrial limit position applications reliably over a long service life. Key engineering features include standard industrial design, ip67, steel body, and the unit mounts via screw mount.
The engineering case for the Omron WL-3A100 Limit Switch rests on a clear set of advantages: standard industrial design, ip67, steel body. Its specifications cover the majority of standard industrial installation scenarios.
Specifications at a Glance
The table below summarises the main technical parameters of the Omron WL-3A100. For full specifications, always refer to the official Omron product datasheet, as application-specific derating may apply.
| Parameter | Value |
|---|---|
| Product Type | Limit Switch |
| Contacts / Channels | SPDT |
| Contact Current | 10 A |
| Key Features | Standard industrial design, IP67, steel body |
| Mounting | Screw mount |
| Mechanical Lifetime | 30 million mechanical operations |
| Operating Temperature | -25 °C to +80 °C |
Industry Use Cases
The Omron WL-3A100 Limit Switch is commonly specified for the following applications:
- General industrial limit position applications
Across these use cases, the consistent thread is a need for dependable switching over a large number of operations, often in environments where an unplanned fault would create significant disruption. The Omron WL-3A100 is designed with exactly those conditions in mind.
Installation Checklist
The Omron WL-3A100 Limit Switch follows standard DIN rail mounting practice. Before inserting the unit into its socket or fixing it to the rail, always verify the circuit is fully de-energised. Check that cable cross-sections are appropriate for the load, and after commissioning, mark the panel clearly with the device type and rated voltage for future maintenance reference.
For ongoing maintenance, periodically inspect for contact discolouration, check terminal screws for loosening, and look for any signs of heat stress on the housing. Catching these early avoids the much larger cost of an unplanned production stop.
