Omron G3RV-SR500-D 230VAC SSR Socket Module: Technical Guide, Applications and Installation
When a machine has to run 24/7, component selection is not about saving a few euros on the BOM — it is about selecting items that will not become a production problem. The Omron G3RV-SR500-D 230VAC SSR Socket Module (220/240V AC) is designed precisely for that reality, with 230V AC load control at the top of its application list.
Omron’s product range extends well beyond relays and switches. The company’s Omron Sensor portfolio covers inductive, photoelectric, and capacitive detection technologies — often integrated into the same panel alongside units like this one, creating a fully cohesive control system.
About the Omron G3RV-SR500-D 230VAC SSR Socket Module
The Omron G3RV-SR500-D 230VAC is a SSR Socket Module rated at 220/240V AC, built to handle 230V AC load control reliably over a long service life. Key engineering features include 230v ac output, slim socket module, and the unit mounts via din rail.
The engineering case for the Omron G3RV-SR500-D 230VAC SSR Socket Module rests on a clear set of advantages: 230v ac output, slim socket module. Operating voltage of 220/240V AC slots neatly into most European and global panel designs.
Specifications at a Glance
The table below summarises the main technical parameters of the Omron G3RV-SR500-D 230VAC. For full specifications, always refer to the official Omron product datasheet, as application-specific derating may apply.
| Parameter | Value |
|---|---|
| Product Type | SSR Socket Module |
| Coil / Operating Voltage | 220/240V AC |
| Contacts / Channels | 1-channel |
| Contact Current | 2 A |
| Key Features | 230V AC output, slim socket module |
| Mounting | DIN rail |
| Mechanical Lifetime | Semiconductor |
| Operating Temperature | -25 °C to +55 °C |
Industry Use Cases
The Omron G3RV-SR500-D 230VAC SSR Socket Module is commonly specified for the following applications:
- 230v ac load control
- Plc output coupling
Across these use cases, the consistent thread is a need for dependable switching over a large number of operations, often in environments where an unplanned fault would create significant disruption. The Omron G3RV-SR500-D 230VAC is designed with exactly those conditions in mind.
Installation Checklist
Commissioning the Omron G3RV-SR500-D 230VAC SSR Socket Module is straightforward. Snap or screw it into position on the DIN rail, connect cables at the correct terminals, and confirm polarity where applicable. During the first powered test, verify that the indicator LED (where fitted) responds correctly and that the output contacts behave as expected under a controlled test load.
For ongoing maintenance, periodically inspect for contact discolouration, check terminal screws for loosening, and look for any signs of heat stress on the housing. Catching these early avoids the much larger cost of an unplanned production stop.
Omron G3RV-SR500-D 230VAC: Long-Term Value
Omron’s reputation in automation did not come from clever advertising. It came from decades of components performing reliably in factories, warehouses, and process plants around the world. The G3RV-SR500-D 230VAC SSR Socket Module is a current embodiment of that engineering culture — nothing superfluous, nothing compromised.
Frequently Asked Questions
What applications is the Omron G3RV-SR500-D 230VAC designed for?
The Omron G3RV-SR500-D 230VAC SSR Socket Module is designed primarily for 230V AC load control, PLC output coupling. Its construction and contact ratings make it well suited to both continuous-duty and intermittent switching in these environments.
What coil voltage does the Omron G3RV-SR500-D 230VAC use?
The Omron G3RV-SR500-D 230VAC operates at a coil voltage of 220/240V AC. Always verify that your control circuit voltage matches before installation.
Does the Omron G3RV-SR500-D 230VAC require a specific socket?
Yes, Omron designs its relay families to work with specific matched sockets. Using a non-specified socket can affect contact pressure and shorten service life. Refer to the Omron G3RV-SR500-D 230VAC datasheet for the compatible socket model.
What certifications does the Omron G3RV-SR500-D 230VAC carry?
Omron products are manufactured to CE and UL standards, with additional certifications depending on the model. Product-specific certification details are available in the official Omron datasheet and on the product label.
Where can I source the Omron G3RV-SR500-D 230VAC in Europe?
The Omron G3RV-SR500-D 230VAC SSR Socket Module is available through Omron’s authorised European distributors. Purchasing through official channels ensures product authenticity, full warranty coverage, and access to technical support.
