Omron G2RV-ST501 24VAC/DC Slimline Relay

The Omron G2RV-ST501 24VAC/DC slimline relay is a compact industrial relay for control panels that require dependable 24 V AC or DC coil operation. It features a 6 mm slim body, integrated socket, SPDT contact form, Push-In Plus terminals, LED indication, mechanical indicator, transparent case, and test button.

Technical Profile

This relay is rated for 6 A carry current and uses silver alloy contacts. It supports interface applications where compact design and reliable switching are required. The 24VAC/DC operating voltage gives panel builders flexibility when designing systems that may use different control voltage standards.

Test Button Advantage

One of the practical strengths of this model is its test button. During commissioning or maintenance, technicians can verify circuit behavior more easily without unnecessary disassembly. The visual LED and mechanical indicator also support faster fault tracing in crowded cabinets.

Common Applications

The relay is widely suited for machine control, motor auxiliary circuits, PLC output interfacing, conveyor systems, packaging equipment, and distributed I/O panels. Its slim format enables higher relay density, while Push-In Plus terminals support consistent wiring quality.

More Information

For related Omron components and control panel solutions, visit Omron automation products.

Omron G2RV-ST501 24VAC/DC FAQ

What type of product is Omron G2RV-ST501 24VAC/DC?

It is a slimline industrial relay with integrated socket, SPDT contacts, 6 A rating, and 24VAC/DC coil operation.

Does it include a test switch?

Yes. This model includes a test button, which helps during commissioning and troubleshooting.

What terminal type does it use?

It uses Push-In Plus terminals for fast, secure wiring.

Can it switch higher current than the ST500-AP models?

Yes. The ST501 series is rated for 6 A, while the ST500-AP versions are designed for microload switching.

Is it appropriate for compact panels?

Yes. Its slim 6 mm class construction is intended for high-density DIN rail installations.
