Omron G2RV-SR700-AP 230VAC Slim I/O Relay Socket

The Omron G2RV-SR700-AP 230VAC slim I/O relay socket is a compact electromechanical interface relay for industrial panels that require a 230 VAC input coil. It is built for applications where panel width is limited, yet the design still needs dependable signal switching and simple wiring access.

Core Design

This unit belongs to the G2RV-SR slim I/O relay range. Its 6.2 mm profile supports high-density panel layouts, while the integrated relay and socket structure reduces component matching work. The SR700 format indicates screw terminal wiring, and the AP contact structure is intended for microload applications.

Contact and Switching Characteristics

The relay uses an SPDT contact form, giving one common, one normally open, and one normally closed path. The AP version includes gold-plated contact material, which makes it relevant for low-current signal circuits. For panel builders, this is useful when standard power relay contacts may be excessive for smaller control signals.

Practical Application Areas

The 230 VAC coil option is commonly relevant in European-style control systems, building automation panels, industrial machinery, auxiliary alarm circuits, and interposing relay applications. It allows a 230 VAC command signal to operate an isolated output contact without consuming much panel space.

Omron G2RV-SR700-AP 230VAC Engineering Considerations

Before specifying this relay socket, check coil voltage, load voltage, load current, contact life expectations, wiring method, and cabinet temperature. Correct use improves long-term reliability and avoids unnecessary maintenance in compact automation assemblies.

Related Information

For additional references, visit Omron automation components.

Omron G2RV-SR700-AP 230VAC FAQ

What type of product is the G2RV-SR700-AP 230VAC?

It is a slim I/O relay socket with a 230 VAC input coil and microload contact configuration.

Is it suitable for small signal switching?

Yes. The AP contact version is designed for microload circuits, making it appropriate for low-level signal switching.

How wide is the relay socket?

The G2RV-SR family is designed with a slim 6.2 mm width, helping reduce panel space.

What terminal type does SR700 use?

SR700 uses screw terminals, which are common in industrial control panel wiring.

Can it be used in PLC interface circuits?

Yes, when the coil voltage and contact ratings match the PLC and field circuit requirements, it can serve as an interposing relay.
