Omron E2E-X1R5D2-M1TGJ-T 0.3M Inductive Proximity Sensor

Technical Overview

The Omron E2E-X1R5D2-M1TGJ-T 0.3M Inductive Proximity Sensor is designed for reliable metal object detection in industrial automation systems. As part of the E2E NEXT family, it combines a compact M8 housing with a shielded sensing structure and a 1.5 mm sensing distance. The sensor is intended for installations where space is limited and accurate target detection is required.

This model utilizes a DC 2-wire configuration and a normally closed output logic. The stainless-steel housing helps withstand demanding industrial conditions, while the M12 Smartclick pigtail connection simplifies installation and replacement procedures.

How the Sensor Works

The Omron E2E-X1R5D2-M1TGJ-T 0.3M Inductive Proximity Sensor operates by generating an electromagnetic field at its sensing face. When a metallic object enters the sensing range, eddy currents are induced in the target material. These currents alter the oscillator characteristics inside the sensor, causing the output state to change.

Because inductive sensing technology detects metallic targets without physical contact, wear on the sensing surface is minimized. This operating principle contributes to long service life in repetitive machine cycles.

Key Technical Characteristics

• M8 cylindrical stainless-steel housing
• Shielded sensing design for flush mounting
• 1.5 mm sensing distance
• Normally closed switching output
• DC 2-wire electrical configuration
• 0.3 m oil-resistant PVC cable with M12 Smartclick connector
• IP67, IP67G, and IP69K environmental protection
• Compact 37.6 mm body length

Industrial Applications

The Omron E2E-X1R5D2-M1TGJ-T 0.3M Inductive Proximity Sensor is commonly integrated into automated machinery where compact sensors are needed for position verification and presence detection.

• Packaging equipment
• Conveyor monitoring systems
• Automated assembly stations
• Material handling equipment
• Machine tool positioning systems
• Industrial robotics
• Metal component transfer systems

Its compact dimensions make it suitable for installations where larger sensor bodies would interfere with machine movement or mechanical assemblies.

Sector-Specific Use Cases

Automotive Manufacturing

Production lines often require verification of metal brackets, fixtures, and stamped components before assembly operations begin. The sensor can detect component presence within compact fixtures.

Food Processing Equipment

With IP69K protection, the sensor can be installed in equipment exposed to intensive washdown procedures while maintaining reliable detection performance.

Packaging Machinery

Packaging systems frequently use inductive sensors to monitor metallic machine elements such as guide rails, actuators, and indexing mechanisms.

Metalworking Facilities

Machining centers and transfer systems can utilize the sensor to confirm workpiece positioning before automated operations are executed.

Advantages of the Sensor

• Compact design suitable for restricted installation spaces
• Non-contact sensing technology reduces mechanical wear
• High environmental protection ratings for harsh conditions
• Flush mounting capability simplifies machine integration
• Oil-resistant cable construction supports industrial environments
• Stainless-steel housing improves durability

For engineers evaluating additional sensing solutions, more Omron sensor products are available for different detection distances and installation requirements.

Omron E2E-X1R5D2-M1TGJ-T 0.3M Factors to Consider When Selecting This Sensor

• Verify that the required sensing distance does not exceed 1.5 mm.
• Confirm compatibility with NC control logic.
• Ensure the application is intended for metallic target detection.
• Check available installation space for an M8 threaded body.
• Review cable routing requirements for the 0.3 m pigtail configuration.
• Consider environmental exposure levels and required ingress protection.

Omron E2E-X1R5D2-M1TGJ-T 0.3M Frequently Asked Questions

What type of targets can this sensor detect?

The sensor is designed for detecting metallic objects using inductive sensing technology.

What is the sensing distance?

The rated sensing distance is 1.5 mm.

Does the sensor support flush mounting?

Yes. Its shielded construction allows flush installation in metal surfaces.

What output configuration does it use?

The sensor uses a DC 2-wire output design.

What does NC operation mean?

Normally Closed operation means the output changes state when a target is detected.

Is the housing resistant to industrial environments?

Yes. The stainless-steel housing is designed for demanding industrial applications.

Can the sensor be used in washdown areas?

Its IP67, IP67G, and IP69K ratings support operation in environments requiring frequent cleaning.

What connection method is provided?

The sensor includes a 0.3 m PVC pigtail cable with an M12 Smartclick connector.

Where is the Omron E2E-X1R5D2-M1TGJ-T 0.3M Inductive Proximity Sensor typically installed?

It is frequently used in packaging machines, assembly equipment, conveyor systems, and industrial automation cells.

Is the Omron E2E-X1R5D2-M1TGJ-T 0.3M Inductive Proximity Sensor suitable for compact machinery?

Yes. Its M8 housing and short body length make it suitable for installations with limited mounting space.
