Omron E2E-X18MC130 2M Inductive Proximity Sensor
| Feature | Value |
|---|---|
| Sensor Type | Inductive Proximity Sensor |
| Series | E2E NEXT |
| Housing Size | M30 |
| Mounting Type | Non-flush (Unshielded) |
| Sensing Distance | 18 mm |
| Output Type | NPN Normally Open (NO) |
| Wiring Method | 3-wire DC |
| Supply Voltage | 10 to 30 VDC |
| Connection Type | 2 m Pre-wired Cable |
| Housing Material | Nickel-Plated Brass |
| Protection Rating | IP67, IP67G, IP69K |
| Operating Temperature | -40°C to +85°C |
| Response Frequency | 100 Hz |
| Body Length | 65 mm |
Technical Description
The Omron E2E-X18MC130 2M Inductive Proximity Sensor is a cylindrical M30 sensor developed for reliable detection of metallic objects in industrial automation environments. As part of the E2E NEXT product family, this sensor incorporates enhanced environmental resistance and stable sensing performance across a broad operating temperature range.
The Omron E2E-X18MC130 2M Inductive Proximity Sensor utilizes an unshielded sensing structure, allowing an extended sensing distance of 18 mm compared to flush-mounted alternatives. Its NPN normally open output configuration supports integration with many PLCs, machine controllers, and industrial monitoring systems.
Working Principle
Inductive proximity sensors detect metallic targets without physical contact. The sensing face generates a high-frequency electromagnetic field. When a conductive metal object enters this field, eddy currents are induced within the target material. These currents modify the oscillation characteristics of the sensor circuit and trigger the output stage.
This contactless detection method minimizes mechanical wear and supports long operational lifecycles in demanding industrial environments. The Omron E2E-X18MC130 2M Inductive Proximity Sensor is therefore suitable for repetitive sensing applications where reliability and consistency are required.
Main Features
- 18 mm sensing distance for metallic target detection
- M30 threaded housing for industrial installations
- NPN normally open output
- 3-wire DC operation
- 2-meter integrated cable connection
- IP67, IP67G, and IP69K protection ratings
- Nickel-plated brass construction
- Wide operating temperature range
- Stable performance in harsh environments
Applications and Usage Areas
The Omron E2E-X18MC130 2M Inductive Proximity Sensor is widely implemented across manufacturing and automation facilities requiring accurate detection of metallic components.
Assembly Lines
The sensor can monitor the presence and position of metal fixtures, tooling elements, and workpiece carriers throughout automated assembly processes.
Conveyor Automation
Industrial conveyor systems use the sensor to identify metal pallets, carriers, and transfer mechanisms while maintaining consistent production flow.
Machine Tools
Metalworking equipment frequently relies on inductive sensors for position verification, actuator monitoring, and machine sequencing operations.
Packaging Equipment
Packaging machinery utilizes proximity sensing technology to confirm mechanical positions and monitor moving machine components.
Industrial Applications
- Automotive body assembly systems
- Metal fabrication machinery
- Material handling equipment
- Automated warehouse systems
- Robotic production cells
- Packaging and processing machinery
- Pallet transfer systems
- Industrial conveyors
Engineers seeking additional sensing technologies can explore Omron sensor series for broader automation requirements.
Advantages
- Non-contact sensing eliminates mechanical wear
- Long sensing range for flexible installation
- Reliable operation in humid and washdown environments
- Durable metal housing construction
- Suitable for continuous industrial operation
- Simple integration with standard control systems
Considerations When Selecting the Sensor
When selecting the Omron E2E-X18MC130 2M Inductive Proximity Sensor, attention should be given to mounting conditions, target material properties, required sensing distance, output compatibility, and cable routing requirements.
Because the sensor uses a non-flush design, sufficient clearance around the sensing face should be maintained to achieve specified detection performance.
Frequently Asked Questions
What type of objects can the sensor detect?
The sensor is designed to detect metallic targets using inductive sensing technology.
What is the rated sensing distance?
The rated sensing distance is 18 mm.
Which output type does the sensor provide?
It features an NPN normally open output configuration.
What voltage range is supported?
The sensor operates from 10 to 30 VDC.
Can it be used in outdoor environments?
The IP67, IP67G, and IP69K protection ratings allow use in demanding industrial environments where moisture and contaminants may be present.
What connection method is used?
The sensor is equipped with a 2-meter pre-wired cable.
Is the sensor suitable for automated production lines?
Yes. It is commonly used in manufacturing, assembly, packaging, and material handling systems.
How does the Omron E2E-X18MC130 2M Inductive Proximity Sensor reduce maintenance requirements?
Its contactless sensing method eliminates mechanical wear associated with traditional contact switches.
