Omron D4A-5109N Safety Limit Switch: Technical Guide, Applications and Installation
The Omron D4A-5109N is a Safety Limit Switch developed for engineers who understand that the cost of an unplanned stop far exceeds the cost of a quality component. it addresses real challenges found in heavy industrial machine safety door locking without overcomplicating installation or maintenance.
Omron’s product range extends well beyond relays and switches. The company’s Omron Sensor portfolio covers inductive, photoelectric, and capacitive detection technologies — often integrated into the same panel alongside units like this one, creating a fully cohesive control system.
Understanding the Omron D4A-5109N Safety Limit Switch
The Omron D4A-5109N is a Safety Limit Switch, built to handle heavy industrial machine safety door locking reliably over a long service life. Key engineering features include coded key, manipulation-resistant, category 4, and the unit mounts via screw mount.
Technically, the Omron D4A-5109N delivers coded key, manipulation-resistant, category 4. Installation is straightforward, which keeps commissioning time short and the panel design clean.
Core Specifications
The table below summarises the main technical parameters of the Omron D4A-5109N. For full specifications, always refer to the official Omron product datasheet, as application-specific derating may apply.
| Parameter | Value |
|---|---|
| Product Type | Safety Limit Switch |
| Contacts / Channels | NC+NO |
| Contact Current | 4 A |
| Key Features | Coded key, manipulation-resistant, Category 4 |
| Mounting | Screw mount |
| Mechanical Lifetime | 1 million mechanical operations |
| Operating Temperature | -10 °C to +55 °C |
