Omron 3G3MX2-AB022-HF Inverter: High-Power Drive for Industrial Excellence

The Omron 3G3MX2-AB022-HF inverter from Omron is a high-performance variable frequency drive (VFD) designed for precision motor control and energy-efficient operation in demanding industrial applications. With advanced harmonic filter features, robust torque performance, and seamless system integration, this inverter is ideal for heavy machinery and factory automation. Explore its technical specifications, installation requirements, and industrial uses to elevate your operations.

Technical Specifications of Omron 3G3MX2-AB022-HFInverter

The 3G3MX2-AB022-HF is engineered for single-phase 200 VAC systems, delivering reliable power for industrial setups. Its compact design and high-power output make it a versatile choice for various applications. Below are the key technical parameters:

Key Features and Industrial Applications

Harmonic Filter and Energy Efficiency

The Omron 3G3MX2-AB022-HF inverter includes a built-in harmonic filter to reduce electrical noise and comply with international standards. This feature ensures clean power delivery, protecting sensitive equipment and improving system longevity. Its energy efficiency class optimizes power consumption, reducing operational costs for heavy machinery like conveyors, hoists, and presses.

Advanced Motor Control and Torque Performance

With 200% starting torque at 0.5 Hz, the 3G3MX2-AB022-HF excels in open-loop vector control, providing precise motor control for cyclic operations. It supports both induction and permanent magnet motors, making it suitable for high-power drive applications in manufacturing, material handling, and food processing.

Network Communication and System Integration

The inverter supports multiple fieldbus protocols, including Modbus-RTU, EtherCAT, DeviceNet, and PROFIBUS, ensuring seamless integration into industrial networks. Its USB port and intuitive programming interface, compatible with Omron’s CX-Drive software, simplify configuration and monitoring, enhancing operational efficiency.

Installation and Maintenance

Installing the Omron 3G3MX2-AB022-HF inverter requires a well-ventilated environment to support its advanced cooling system, which maintains performance under heavy loads. The IP20-rated enclosure protects against dust, while regular maintenance—such as inspecting cooling fans and terminal connections—ensures long-term reliability. Technical documentation, available through Omron’s official channels, provides detailed installation requirements and maintenance procedures.

Safety Certifications and Protection Features

The 3G3MX2-AB022-HF meets stringent safety standards, including ISO 13849-1 (Cat 3/PLd) for Safe Torque Off (STO) and CE, UL, and cUL certifications. Built-in protection features like overcurrent, overvoltage, and thermal overload safeguards ensure safe operation in demanding environments.

Price Comparison and Value

While pricing varies by distributor, the 3G3MX2-AB022-HF offers competitive value due to its robust features and energy-saving capabilities. For accurate price comparisons, contact authorized distributors like InvertersUK or RS Components, ensuring warranty coverage and technical support.

Why Choose the Omron 3G3MX2-AB022-HF Inverter?

The Omron 3G3MX2-AB022-HF inverter combines high-power performance, advanced harmonic filtering, and versatile communication options, making it a top choice for industrial applications. Its compact design, reliable cooling system, and comprehensive safety certifications ensure optimal performance in heavy machinery and automation systems. Invest in the 3G3MX2-AB022-HF for superior motor control, energy efficiency, and long-term reliability.
