Elesа+ganter 11361 HCX.254-M12 Column Level Indicator

The elesа+ganter 11361 HCX.254-M12 column level indicator is designed for visual monitoring of fluid levels in larger hydraulic tanks, oil reservoirs and industrial machine housings. The HCX.254 format indicates a longer level reading body than compact models, making it useful where a wider fluid level range must be observed.

Elesa+Ganter 11361 Technical Features

This model uses an M12 mounting connection and is listed as a column level indicator for industrial use. HCX series indicators are known for transparent technopolymer construction, sealing elements and clear visibility from different viewing angles. For HCX.254, technical references also indicate a 12.5 mm mounting hole and 12 Nm tightening torque, supporting controlled installation.

Industrial Use Cases

Large hydraulic power units, lubrication tanks and production machinery often require simple but reliable level checks. A long column indicator helps operators see whether the fluid is within the correct working range. This supports daily inspections, service planning and early identification of leaks or abnormal consumption.

To explore more Elesa+Ganter products, visit Elesa+Ganter technical components.

Elesa+Ganter 11361 FAQ

What is the product type of Elesa+Ganter 11361?

It is an HCX.254-M12 column level indicator used for visual liquid level monitoring.

What does 254 mean in HCX.254?

It refers to the model size and indicates a longer level indicator body compared with smaller HCX versions.

Why is M12 important?

M12 defines the mounting connection size and helps ensure compatibility with the tank’s installation points.

Is this suitable for hydraulic systems?

Yes, it is commonly used for hydraulic tanks and oil reservoirs, provided the operating conditions match the product limits.
