Weidmüller 1000970000 BLDF 5.08/05/180F SN BK BX: Technical Guide to a 5-Pole Female PCB Plug
The Weidmüller 1000970000 BLDF 5.08/05/180F SN BK BX is a 5-pole female PCB plug intended for industrial electronics where removable wire connection, dependable contact quality, and efficient installation all matter. This kind of connector is especially attractive in applications where engineers want a practical balance between compact size and useful connection capacity. A five-pole configuration is often a very efficient middle ground for modular board design.
Main Product Characteristics
The full name Weidmüller 1000970000 BLDF 5.08/05/180F SN BK BX female plug identifies a connector with a 5.08 mm pitch, 5 poles, and a 180-degree straight conductor outlet. It belongs to the BLDF family and uses PUSH IN with actuator technology. This is an important combination because it supports fast conductor insertion, controlled release, and a straightforward wiring experience in both production and service situations.
The 5.08 mm pitch also remains a strong design choice in industrial electronics because it provides comfortable access for wiring while keeping the product compact enough for modern board layouts.
Why a 5-Pole Connector Is So Useful
The Weidmüller BLDF 5.08/05/180F SN BK BX works well in systems where several related signals or mixed control functions need to be grouped into one pluggable connection. Five-pole formats often appear in compact controllers, interface electronics, alarm systems, machine subassemblies, and monitoring devices. They are large enough to be versatile but still easy to integrate into small enclosures.
In addition, a pluggable connection can make field maintenance more efficient. Instead of handling individual hard-wired conductors on the board during service, technicians can often remove or replace the connectorized section more cleanly. That can improve uptime and reduce intervention time.
Electrical and Operational Perspective
The Weidmüller 1000970000 female plug belongs to a connector family with solid industrial rated data and a broad conductor range. This gives design teams flexibility in matching the connector to real-world wiring requirements. The PUSH IN with actuator concept also makes the product easier to work with under installation pressure, which matters in both factory assembly and field commissioning.
Products like this are not only selected for datasheet values. They are chosen because they make the entire connection process more manageable, from panel assembly to maintenance years later.
Typical Application Areas
The Weidmüller 1000970000 BLDF 5.08/05/180F SN BK BX female plug is relevant in industrial automation, compact controller boards, machine interface modules, relay assemblies, building technology products, and service-friendly PCB-based equipment. It is especially useful where a removable multi-pole connection improves handling and maintenance access.
Searches often include Weidmüller 1000970000, Weidmüller BLDF 5.08/05/180F SN BK BX, and Weidmüller 5-pole female PCB plug.
FAQ
What type of product is Weidmüller 1000970000?
It is a female PCB plug designed for pluggable wire-to-board connection.
How many poles does it have?
This model has 5 poles.
What pitch does the connector use?
The connector uses a 5.08 mm pitch.
What technology is used for wire connection?
It uses PUSH IN with actuator technology for fast wiring and easier conductor release.
Why is a pluggable connection useful?
It can simplify installation, improve serviceability, and make module replacement more efficient in the field.
Where is the connector commonly applied?
It is commonly applied in automation electronics, control boards, machine interfaces, and modular industrial devices.
For more about Weidmüller, comparing this connector with other BLDF variants can help streamline product family planning.
