Advantech IPS-150 Industrial Power Supply
The Advantech IPS-150 Industrial Power Supply is an intelligent uninterruptible power supply module intended to maintain temporary power for compatible industrial computers and panel PCs when the main DC input is interrupted. By supporting an automatic and controlled computer shutdown, the module helps reduce the risk of data loss, file corruption, and sudden operating-system failure. Customers can contact Emaconn for current pricing, stock information, delivery estimates, and technical product selection assistance.
Power Continuity for Industrial Computers
Industrial computers often operate continuously within machine control, production monitoring, and process supervision systems. A sudden power interruption can stop active software processes and prevent important operating data from being saved correctly. The IPS-150 provides temporary power during this transition, allowing compatible equipment to complete a managed shutdown procedure.
The module operates with a nominal 24 VDC input and supports an input range of 24 VDC ±20%. It delivers a 24 VDC output within the stated tolerance. The typical output current is 5 A, with short-duration support of up to 6.25 A for approximately three to five seconds. The connected computer and peripheral load must remain within the supported electrical capacity.
Intelligent Monitoring and Automatic Shutdown
The IPS-150 does more than provide short-term battery power. It communicates with the connected industrial computer to monitor operating conditions and initiate an automatic shutdown according to the configured timing. This functionality is valuable where a computer must close applications and the operating system safely before backup energy is depleted.
An isolated RS-232 interface is provided for system monitoring and configuration. A software utility allows technicians to manage settings and review module status. LED indicators provide visible information about the battery pack and input power, supporting faster inspection during commissioning and maintenance.
Operating-system compatibility should be verified before implementation. Supported environments include Windows 10 LTSC, Windows 11, and Linux, but suitability may depend on the specific computer model, software image, drivers, and configuration used in the application.
Battery Configuration and Protection
The unit uses a 14.4 VDC, 6900 mAh lithium-ion battery pack. Integrated over-discharge protection helps reduce battery damage caused by excessive discharge. The battery pack is replaceable, allowing maintenance teams to renew the energy-storage component without replacing the complete power management module.
Actual backup duration is influenced by the connected load, battery condition, charging status, operating temperature, and configured shutdown time. For this reason, the module should be tested with the intended computer and application rather than selected according to battery capacity alone.
Battery condition should be included in preventive maintenance planning. If the module remains unused for an extended period, the battery should retain an appropriate charge level and be recharged periodically to reduce the risk of deep discharge during storage.
Applications in Automation and Machine Systems
The Advantech IPS-150 can support industrial computing equipment used in applications such as:
- Machine control and operator interface systems
- Panel PC installations in automation environments
- Production monitoring and data collection stations
- Process visualization and supervisory control
- Industrial terminals handling active operational data
- OEM machinery requiring managed computer shutdown
The module is associated with selected Advantech PPC-300, PPC-400, TPC-B520, TPC-B300, TPC-100, and TPC-300 series equipment. The exact computer model and its power requirements must be checked before purchase. Compatibility should not be assumed only because the connected device belongs to one of these product families.
Mounting and Environmental Requirements
The module is housed in a metal enclosure measuring approximately 196.9 × 157.5 × 42.7 mm. It supports DIN-rail mounting for control cabinet installations and VESA 75/100 mounting for positioning behind compatible panel PCs.
Power is connected through a four-pin terminal block. Installation planning should also account for the control and communication connections required by the shutdown function. Qualified personnel should verify polarity, grounding, connector security, cable routing, and communication before the system is placed into service.
The specified operating temperature range is 0 to 40°C. Relative humidity may reach 95% at 40°C when condensation is prevented. Cabinet design should provide suitable ventilation and protection against excessive heat, moisture, contamination, shock, and vibration.
Essential Checks Before Procurement
Purchasing teams should confirm the full product designation and compare it with the machine documentation. The following information should be reviewed before ordering:
- Industrial computer or panel PC model
- Normal and peak power consumption
- Available 24 VDC input supply
- Required backup and shutdown behaviour
- Operating system and software compatibility
- Control cable and connector requirements
- DIN-rail or VESA mounting preference
- Ambient and cabinet conditions
Required cables, mounting hardware, and replacement battery needs should be identified during the same review. This approach can reduce installation delays and prevent incomplete procurement.
Source the Advantech IPS-150 Through Emaconn
Emaconn provides international procurement support for companies seeking the Advantech IPS-150 for automation projects, equipment maintenance, or replacement planning. Current price, availability, estimated lead time, and quotation conditions can be requested according to quantity and delivery destination.
Buyers should provide the complete product reference, required quantity, connected computer model, delivery country, and requested schedule. For larger projects, Emaconn can also evaluate bulk procurement, scheduled supply, related accessories, and alternative Advantech models.
Advantech IPS-150 Additional products can be reviewed on the Advantech industrial automation solutions page. Technical and commercial information should be confirmed before placing an order, particularly when the module is intended to replace an existing power system.
Conclusion
The Advantech IPS-150 Industrial Power Supply supports temporary 24 VDC power and controlled shutdown for compatible industrial computers and panel PCs. Selection should consider computer compatibility, load demand, input supply, communication, operating system, mounting, battery maintenance, and environmental conditions. Emaconn can support current pricing, availability checks, quotations, accessory selection, and alternative-product assessment. Submit the system details to confirm technical suitability and procurement conditions.
Advantech IPS-150 Frequently Asked Questions
What does the Advantech IPS-150 do?
It provides temporary power during an input interruption and supports the controlled shutdown of compatible industrial computers.
What is the required input voltage?
The module uses a nominal 24 VDC input and supports a specified range of 24 VDC ±20%.
What output current is available?
The typical output current is 5 A, with short-duration support up to 6.25 A under specified operating conditions.
Does the IPS-150 include monitoring functions?
Yes. It provides status indicators, an isolated RS-232 interface, and software-based configuration and monitoring.
Can it be installed on a DIN rail?
Yes. The enclosure supports DIN-rail mounting as well as VESA 75/100 installation.
How should battery condition be maintained?
Test backup operation periodically, avoid deep discharge, and follow the recommended charging and storage practices.
How can I obtain the latest price?
Request a quotation using the complete product reference, quantity, destination, and required delivery schedule.
How can stock availability be confirmed?
Submit an enquiry before ordering because availability and lead time can vary by quantity, date, and destination.
Can related cables or spare batteries be supplied?
Compatible accessories and spare components can be evaluated according to the selected system and requested configuration.
Can Emaconn help identify an alternative model?
Yes. An alternative can be assessed after the load, input supply, computer model, connections, mounting, and environmental requirements are reviewed.
